Illustrative image of stacked steel plates in a stockyard (not Jayesh Steel stock)
Illustrative image · not our premises or stock

Aisle stop 06 / 08 · Plates

Structural Plate

Structural Steel Plate

Structural plate grades are specified for load-bearing fabrication: buildings, bridges, cranes, trailers and towers. Weather-resistant (weathering) grades form a protective patina that reduces maintenance.

The size ranges and grades below were published on the previous jayeshsteel.com product pages and still need confirmation.

Request a quote for Structural Plate Next: AR Plate

Size range

Thickness5 mm – 200 mm
Width1500 mm – 4500 mm
Length / form6 m – 18 m

Other sizes may be available on request. Ask for your exact dimensions.

Grades

Standard structural

  • S235 / S275 / S355 (JR, J0, J2, K2)EN 10025-2
  • ASTM A572 Gr. 42 / 50 / 60 / 65ASTM A572
  • IS 2062 E350 / E410 / E450IS 2062

Weathering & shipbuilding

  • ASTM A588 Gr. A / B / C / KASTM A588
  • S355J0WP / S355J2WPEN 10025-5
  • Grade A / B / D / E; AH32 – EH40Class society

Typical applications

  • · Buildings and sheds
  • · Bridges
  • · Wind towers
  • · Trailer and vehicle chassis
  • · Shipbuilding
  • · Heavy machinery

Source mills

SAIL · JSW · TATA Steel · Jindal Steel & Power · ArcelorMittal

Jayesh Steel is a trader. Material is produced by steel mills, not by Jayesh Steel. Mill test certificate availability: to confirm.
